Plexiglass plate, without any coloring additives, absolutely transparent, light transmittance up to 92%. Environmental protection and thermoplasticity. The ignition temperature of the material is about 400 °C. Plexiglass has gained the ability to be used in a large temperature range of - 40 to + 90 °C and to improve its strength.
The thickness can be between 1.0mm and 120mm.
Size 1500mm * 1700mm. 1220mm * 2250mm
|Thermal deformation temperature(1.8MPA)||101|
|Linear expansion coefficient ℃-1||7.0*10-5|
|Heating dimensional change (shrinkage) %||1.9|
|Tensile Strength Mpa||74.7|
|Tensile strain at break %||6.2|
|Tensile elastic modulus Mpa||3010|
|Vicat softening temperature (B50),℃||106|
|Anti-solvent silver grain (4H)||No silver grain|
|Charpy impact strength KJ/M2||21.9(C)|
|2-25mm||1240*1840mm, 1250*1870mm, 1240*2440mm, 1250*2470mm, 1210*2360mm, 1320*2540mm, 1380*2620mm, 1490*2990mm, 2080*3080mm, 1850*2450mm, 1660*2600mm.|
|30-200mm||1200*1800mm, 1200*2400mm, 1300*2500mm, 1500*2500mm, 2500*3500mm, 2000*10000mm.|
