Fiberglass fabric-used as an insulator in motors with temperatures up to 155 °C (Class F).
It can be used in various electrical and electromechanical equipment to achieve reliable insulation. Glass paint fabrics are used as flexible insulation materials in motors, equipment, and electrical, moisture, and thermal insulation for pipes and pipelines.
It is delivered to the destination in roll form with a thickness of 0.10-0.20 mm.
|Model No.||Product Name||Components||Tmp. Class||Features and Applications|
|Basic Material||Impregnated Varnished|
|2210||Oil varnished silk||Silk||Oil varnish||A (105 °C)||-Excellent softness and electric property.
-As liner and coil insulation for motors and electric appliances.
|2310||Oil varnished synthetic cloth||Synthetic fabric|
|2432||Alkyd varnished glass cloth||E-glass fiber cloth||Alkyd resin||B(130 °C)||-Excellent dielectric, mechanical property and heat resistance, good oil, fungus and humidity-heat resistance.
-As coil insulation for oil-immersed transformers and oil circuit breakers.
|2450||Silicone varnished glass cloth||Organic silicone varnish||H(180 °C)||-Excellent heat resistance, elasticity,good fungus, cold and oil resistance.
-As coil insulation for H-Grade motors and electric appliances.
